The Linear Optical Axis Retaining Ring is an annular elastic component used in mechanical transmission systems to achieve axial positioning and fixation of components on the axis. It is usually mounted in the circular groove on the optical axis, and fixes itself on the groove wall through its elastic tension to prevent axial movement (left-right displacement) of components such as gears, bearings, and pulleys on the axis, thereby ensuring the stability and reliability of the mechanical structure.
product highlights
Flexible positioning, easy installation, continuous improvement, advanced technology
Precision Machining for Accurate Positioning
The shaft retaining ring undergoes CNC precision machining, with tolerance controlled within ±0.02mm. It fits perfectly with the shaft/hole surface, effectively preventing axial movement.
High-Strength Material for Harsh Environments
Made of aluminum alloy or stainless steel (304/316), and processed through quenching and tempering treatment, it reaches a hardness of HRC 42-48, suitable for high-load and vibrating environments.
Easy Installation for Improved Efficiency
No additional tools are required. The elastic opening design allows direct embedding into the groove, increasing installation efficiency by 50%.
Professional
The surface is treated with zinc (Zn) plating, nickel (Ni) plating, or black oxide treatment. It passes over 100 hours of salt spray testing and can adapt to harsh environments such as humidity, dust, and acid-alkali conditions.
Product parameter information
Application scenarios
Widely used in mechanical gearboxes, electric motors, automotive parts, industrial equipment, aerospace and other fields, suitable for axial positioning of gearboxes and bearing housings, fixing stable motor rotors and pump shafts, and limiting control of sliding guides and ball screws in automation equipment.
our factory
why choose us
Factory Direct
15 years of industry experience, independent R&D and production, and custom orders based on provided drawings/samples.
Fast Delivery
Regular specifications are shipped within 72 hours, and non-standard samples are available within 2 weeks.
Quality Assurance
Full-process ISO9001 quality control, material reports and inspection certificates provided for each batch.
Professional Service
Engineering team provides online technical support and optimized selection recommendations.
Installation Guide
- Check if the dimensions of the shaft/hole groove match the retaining ring specifications.
- Use special circlip pliers or fingers (for small sizes) to expand the ring and align it with the groove.
- Verify that the Linear Optical Axis Retaining Ring is fully seated without warping or gaps.
